NAD 906

SPECIFICATIONS

Stereo Mode

Continuous Average Power Output into 8 OHMS

(Min. power per channel, 20 Hz – 20 kHz, both channels driven with no more than rated distortion)

===> 30 W (14.8 dBW)

———-

Rated Distortion (THD 20 Hz – 20 kHz)

===> 0.05%

———-

Clipping Power (maximum continuous power per channel)

===> 38 W

———-

IHF dynamic headroom at 8 ohms

===> +2 dB

———-

IHF dynamic power (maximum short term power per channel)

8 ohms

4 ohms

2 ohms

===> 48 W (16.8 dBW)

===> 65 W (18.0 dBW)

===> 85 W (19.3 dBW)

———-

Input impedance

===> R = 10 k ohm

===> C = 470 pF

———-

Input sensitivity (for rated power into 8 ohms)

===> 1 V

———-

Voltage gain

===> x15.5 (23.8 dB)

———-

Frequency response 2 Hz to 100 kHz

===> +0, -3dB

———-

Signal/Noise ration, A-weighted 95 dB ref. 1 W

THD (Total Harmonic Distortion, 20 Hz – 20kHz, from 250 mW to rated output)

===> <0.05%

———-

SMPTE I.M. (Intermodulation distortion, 60 Hz + 7kHz, 4:1 from 250 mW to rated output)

===> <0.05%

———-

IHF I.M. (CCIF IM distortion, 19 + 20kHz at rated output)

===> <0.05%

———-

Bridged (Monophonic) Mode

Continuous Average Power Output into 8 OHMS

(Min. power per channel, 20 Hz – 20 kHz, both channels driven with no more than rated distortion)

===> 90 W

———-

IHF dynamic headroom at 8 ohms

===> +2 dB

———

IHF dynamic power (maximum short term power per channel)

8 ohms

4 ohms

===> 140 W (21.5 dBW)

===> 170 W (22.3 dBW)

Bezahlung per Überweisung, Nachnahme, Paypal oder Barzahlung bei Abholung!!
Wir geben 12 Monate Gewährleistung – Da können Sie sicher sein, ein funktionierendes Gerät zu bekommen!
Gerne kaufen wir ihre Hifigeräte und Lautsprecher auch an!
Wenn sie defekte Geräte haben, können sie die auch gerne anbieten!
