Marantz PM-6a

Description

Features of the Marantz PM-6A include a MC head amplifier (13 transistors for each channel), phono amplifier (11 transistors for each channel), quarter A system, FET voltage amplifier and a speaker protection circuit.

Specifications

Power output: 120 watts per channel into 8Ω (stereo)

Frequency response: 10Hz to 80kHz

Total harmonic distortion: 0.03%

Damping factor: 120

Input sensitivity: 0.22mV (MC), 2.2mV (MM), 150mV (line)

Signal to noise ratio: 90dB (MM), 98dB (line)

Output: 150mV (line)

Dimensions: 416 x 146 x 332mm

Weight: 15.5kg
