Advance Acoustic MAP-101

Technische Daten

Ausgangsleistung: 8 Ohms 2 X 45 W

FREQUENCY RESPONSE (-3 DB ): 10 Hz – 65 kHz

S/N RATIO: ≥ 90 dB

CHANNEL SEPARATION:  ≥ 90 dB

INPUT IMPEDANCE: 10 kΩ

INPUT IMPEDANCE PHONO (MM): 47 kΩ

IN LEVEL (CD,AUX): < 550 mV

IN LEVEL AMPLIFIER: 1,25 V

IN LEVEL PHONO (MM): 2,5 mV

AC INPUT: 230 V

P.CONSUMPTION: MAX < 180 W

TRANSFORMERS NUMBER: 1 (200 VA)

Abmessungen (H X B X T): 10 X 43,5 X 33 cm

Gewicht: 7 kg
